Replacement Of AW31705 Wing Lift Hydraulic Cylinder

The Replacement Of AW31705 Wing Lift Hydraulic Cylinder is a hydraulic cylinder used for lifting wings. It is designed to replace the original cylinder AW31705, with improved performance. The cylinder is an essential part of the hydraulic system, which enables the wings of the device to be lifted. It plays a critical role in the proper functioning of the device.

Specifications and Models

Specifications

• Weight: 30.8 lb
• Height: 3.7 in
• Width: 3.8 in
• Length: 26.3 in

Models

The Replacement Of AW31705 Wing Lift Hydraulic Cylinder is compatible with the following models:

• 2018 CX15
• HX15
• MX15

Features

There are several key features of the Replacement Of AW31705 Wing Lift Hydraulic Cylinder. These include:

Improved Equipment Performance

Replacing a damaged or worn hydraulic cylinder can restore the equipment’s normal operating capacity, ensuring its performance in a variety of applications.

Enhanced Safety

Regularly replacing hydraulic cylinders can reduce safety hazards caused by cylinder failure, ensuring the safety of operators and equipment.

Overload Protection

New cylinder designs usually consider better overload protection mechanisms, improving safety.

Quick Installation

Modern hydraulic cylinder designs are usually easy to install and replace, reducing downtime.

Standardized Components

Many hydraulic cylinders are standardized products, making it easy to obtain replacement parts in the market.

We can produce this product, and our product can perfectly replace these hydraulic cylinders.

Applications

Here are some examples of where the Replacement Of AW31705 Wing Lift Hydraulic Cylinder can be used:

Excavator

The hydraulic cylinder in the arm or bucket of the excavator may be damaged due to long-term use or overload and need to be replaced to restore normal operation.

Crane

The crane’s boom hydraulic cylinder is easily worn during frequent lifting and lowering, requiring regular replacement to ensure safety.

Tractor

The hydraulic cylinder of the front-end loader of the tractor may leak or decrease in performance during continuous lifting and tilting operations and need to be replaced.

Harvester

During the harvesting process, the hydraulic system is under high pressure, and the cylinder may be damaged due to fatigue, requiring timely replacement to maintain work efficiency.

Automated Production Line

Hydraulic cylinders are used to control robotic arms and other automation equipment. If the cylinder fails, it can affect production efficiency and requires immediate replacement.

Die Casting Machine

Under high-pressure and high-temperature environments, the hydraulic cylinder may experience performance degradation. Regular replacement can ensure product quality.

Mining Equipment

Hydraulic cylinders are used in mining equipment to lift and move heavy objects. Due to the harsh working environment, regular inspection and replacement are required to avoid equipment failure.

Bulldozer

The wear of the hydraulic cylinder on the bulldozer’s push arm can cause a reduction in push capacity and requires timely replacement to maintain operational efficiency.

Maintenance

Regular maintenance is essential to ensure the optimal performance and longevity of the Replacement Of AW31705 Wing Lift Hydraulic Cylinder. Here are some common maintenance tasks:

Regular Inspection

Regular inspection of the cylinder and the hydraulic system can detect any problems early and prevent damage to other components.

Proper Lubrication

Hydraulic cylinders require proper lubrication to operate smoothly. Regularly adding the appropriate amount and type of hydraulic oil can prolong its lifespan.

Seal Replacement and Calibration Check

Regularly replacing worn seals and checking the calibration of the cylinder can ensure its optimal performance.

It is important to provide proper guidance for cylinder alignment during installation, recommend the use of appropriate mounting brackets to fix the cylinder, and provide recommended inspection, repair, and replacement procedures, as well as parts replacement and rebuilding services, to extend the life of the cylinder.

Safety and Environment

Safety is a top priority when working with hydraulic cylinders. Proper safety measures should always be followed when handling the cylinder. Environmental considerations should also be taken into account when disposing of the cylinder.

Troubleshooting and Common Issues

Here are some common issues that may arise when using the Replacement Of AW31705 Wing Lift Hydraulic Cylinder:

Fluid Leaks

Fluid leaks are a common problem with hydraulic cylinders. They can be caused by worn seals or a damaged cylinder. Regular inspection and replacement of seals can prevent fluid leaks.

Slow or Uneven Movement

If the cylinder is moving slowly or unevenly, it may be due to insufficient lubrication, worn seals, or a damaged cylinder. Proper lubrication and regular inspection and replacement of seals can help prevent this issue.

No Movement

If the cylinder is not moving at all, it may be due to a lack of hydraulic fluid, a clogged filter, or a damaged cylinder. Checking the fluid level, replacing the filter, and inspecting the cylinder for damage can help resolve the issue.

Design Considerations and Selection Criteria

When selecting a hydraulic cylinder, it is important to consider its load-bearing capacity, sealing performance, durability, safety, and maintainability. These factors can affect its performance and lifespan. The Replacement Of AW31705 Wing Lift Hydraulic Cylinder is designed with these factors in mind, ensuring its optimal performance and longevity.

The cylinder uses various seals, such as piston seals and rod seals, made of wear-resistant materials such as polyurethane and nitrile rubber. The cylinder body and threaded end surfaces are finely processed to improve wear resistance. Regularly adding the appropriate amount of hydraulic oil can prolong its lifespan. Regular inspection, proper lubrication, and replacement of worn seals are essential for its optimal performance.
